Product Specs
Engine Specifications
- Maximum Rating
- 135 ekW (170 kVA)
- Minimum Rating
- 110 ekW (138 kVA)
- Emissions/Fuel Strategy
- NSPS or non-regulated
- Aspiration
- Turbocharged-Aftercooled
- Manifold Type
- Watercooled
- Bore
- 4.75 in
- Stroke
- 6 in
- Displacement
- 640 in³
- Engine Control and Protection
- ADEM A4
- Generator Set Control
- EMCP 4.3 (4.4 optional)
- Generator
- SR4B
- Frequency - Speed
- 1800 rpm
Capacity for Liquids
- Fuel
- CNG, LNG, field gas, natural gas
- Lube Oil System - Refill
- 12 gal (US)
- Cooling System - Engine
- 5 gal (US)
Dimensions
- Length
- 60 in
- Width
- 38 in
- Height
- 50 in
- Weight
- 948 lb
Standard Equipment
-
- Air Inlet System
-
- Air cleaner — intermediate duty, dry
- Air cleaner rain cap
- Air cleaner service Indicator
-
- Cooling System
-
- High ambient radiator design for gas fuel applications
- Side-by-side aftercooler and jacket water core
- Metal top and bottom tanks
- Coolant drain
- Fan and belt guard
- Coolant level sensor
-
- Exhaust System
-
- Exhaust manifolds — water cooled
- Exhaust elbow and flex fitting — 127 mm (5 in)
- Residential grade muffler
-
- Fuel System
-
- Gas pressure regulator — requires 82.7-172.4 kPa (12-25 psi) gas
- Natural gas carburetor
-
- Generator
-
- Rated for continuous duty — 25% oversize
- Class H insulation
- Permanent magnet
- Random wound
- 240 VAC space heater
- Coastal insulation protection
- IP23 protection
- Cat Digital Voltage Regulator
-
- Control System
-
- Electronic governing ADEM A4
- Electronic diagnostics and fault logging
- Momentary start/stop logic
- High temperature braided engine harness with 70-pincustomer connector and service tool connector
-
- Lube System
-
- Crankcase breather, top-mounted
- Oil filter, spin-on, left-hand service
- Dipstick, left-hand service
- Oil pump — gear-driven
- Oil cooler
-
- Mounting System
-
- Heavy-duty welded steel base designed for the oilfield
- Designed to accommodate a drop-over enclosure
- Space claims for makeup tank and coalescing filter
- Base design optimized for loading, transport, and unloading
-
- Protection System
-
- The following parameters include alarm and shutdown:
-
- General
-
- Jacket water heater
- 24V starting motor
- 24V, 45-amp charging alternator
Attachments
-
- Exhaust System
-
- Three-way catalyst
- Critical grade muffler
- Muffler mounting structure
-
- Fuel System
-
- Air-fuel ratio control
- Coalescing filter, heavy-duty for wellhead gas
