Exterior View
Product Specs
Generator Set Specifications
- Maximum Rating
- 1500 kVA
- Minimum Rating
- 910 kVA
- Emissions/Fuel Strategy
- Low Fuel, Low Emissions
- Voltage
- 400 to 3300 Volts
- Frequency
- 50 Hz
- Speed
- 1500 rpm
- Duty Cycle
- Standby, Mission Critical, Prime, Continuous
Engine Specifications
- Engine Model
- C32 TA, V-12, 4-Stroke Water-Cooled Diesel
- Bore
- 5.71 in
- Stroke
- 6.38 in
- Displacement
- 1958.86 in³
- Compression Ratio
- 15.0:1
- Aspiration
- Turbocharged, Air to Air Aftercooled
- Fuel System
- MEUI
- Governor Type
- Adem™A4
Generator Set Dimensions
- Length - Minimum
- 164 in
- Length - Maximum
- 176.6 in
- Width - Minimum
- 66.3 in
- Width - Maximum
- 87.8 in
- Height - Minimum
- 85.1 in
- Height - Maximum
- 86.4 in
- Dry Weight - Genset (minimum)
- 14700 lb
- Dry Weight - Genset (maximum)
- 17855 lb
Standard Equipment
-
- Air Inlet System
-
- Single element canister type with service indicator
-
- Control Panel
-
- GCCP Control panel
- Warning shutdowns
- Programmable protective relaying functions
- Communications
- Digital indicators
- Control features
-
- Cooling System
-
- Radiator fan and fan drive
- Coolant drain line with valve
- ATAAC
- Caterpillar extended life coolant
- Fan and belt guards
- Low coolant level sensor
-
- Exhaust
-
- 203 mm (8 in) ID round flanged outlet
- Exhaust manifold - dry
-
- Fuel System
-
- Fuel cooler
- Secondary fuel filters
- Primary fuel filter with water separator
- Fuel priming pump
-
- Generators And Attachments
-
- Permanent magnet excitation (PMG)
- Reactive droop
- Integrated voltage regulator (IVR)
- 6 Lead
- Salient pole
- Class H temperature rise at 40C ambient
- Busbar connections, top center mounted, top cable entry
- Internal excitation (IE)
- 3 Phase brushless
- Winding temperature detectors
- IEC standard hole pattern
- NEMA Class H insulation
-
- Governing System
-
- ADEM(tm) A4
-
- Mounting System
-
- Rails - engine/generator/radiator mounting
- Rubber anti-vibration mounts
-
- Lube System
-
- Fumes disposal
- Integral lube Oil cooler
- Oil filter, filler and dipstick
- Gear type lube oil pump
- Lubricating oil
- Oil drain lines and valve
-
- Power Termination
-
- Busbar
-
- Starting / Charging System
-
- Battery disconnect switch
- 45 Amp Charging alternator
- 24 Volt electric starting motor
- Battery, rack and cables
-
- General
-
- SAE standard rotation
- RH service
- Flywheel and flywheel housing-SAE
- Caterpillar yellow with high gloss black rails & radiator
Attachments
-
- Air Inlet System
-
- Standard air cleaners
- Dual element air cleaner
- Heavy duty air cleaner
-
- Circuit Breakers
-
- Shrouds
- Enclosures - Control packaging
- 1600, 2000, 2500 and 3200 Amp, 3 Pole, IEC-Rated Circuit breakers
- Cable supports
- Circuit breaker wiring groups
- Power connection covers
- Center posts busbars
- 800, 1600, 2000, 2500 and 3200 Amp, 4 Pole, IEC rated Circuit breakers
- 400, 800, 1200, 1600, 2000, 2500 and 3000 Amp, 3 Pole, UL-100% Rated Circuit breakers
-
- Control Panels
-
- GCCP Control panel
-
- Cooling System
-
- High ambient radiator
- Extended life coolant
- Radiator duct flange
- Standard radiator
- Certified radiator
-
- Enclosures
-
- AC Panel, outlets and lights
- Premium sound attenuated enclosure
- Enclosure louvres - fixed and motorized
- Enclosure fuel tank options
- Color options
- Panel bracket
- Sound attenuated enclosure
- DC lighting package
- Cold weather bundle
-
- Exhaust System
-
- All C32 engines have 203 mm (8 in) exhaust outlets
- Mufflers
- Elbow mounting kit
- Flange and exhaust expanders
- Flexible fittings
- Guard and shield system
- Flanges
- Exhaust through the wall kit
-
- Generator And Attachments
-
- Medium voltage generators
- Low voltage generators
-
- Lube System
-
- Oil pan
- Prelube manual sump pump
- Oil level regulator
-
- Mounting System
-
- IBC vibration isolators
- Spring type vibration isolators
- Standard package isolators
- Mounting base types
-
- Power Termination
-
- Circuit breakers, IEC compliant
- Circuit breakers, UL listed
-
- Power Connections
-
- Center post busbars
- Neutral grounding connection
- Low voltage connection cables
-
- Starting / Charging System
-
- Electric starting motor - Standard/heavy duty
- Space heater
- Standard 24 volt open package battery set - Dry
- 10 Amp Battery charger
- 20 Amp Battery charger
- Jacket water heater
- 10 Amp enclosure Battery charger
- 35 Amp Battery charger
-
- Special Tests / Reports
-
- Standard engine test
- OSHPD seismic Certifications
- Generator test report
- Custom generator TVA report
- Standard genset Torsional Vibration Analysis (TVA) report
- IBC seismic Certifications
- PGS Test report @ 0.8 power factor
- PGS Test report @ 1.0 power factor
- CSA test and certification
-
- General
-
- Special paint
- US aid emblem
