Product Specs
Generator Set Specifications
- Continuous Rating
- 2000 ekW @1.0pf
- Fuel Type
- Natural Gas, Biogas, Coal Gas
- Maximum Electrical Efficiency
- 43.70%
- Maximum Standby Rating
- 2000
- Frequency
- 50 / 60 Hz
- RPM
- 1500
Engine Specifications
- Engine Model
- CG170-20
- Displacement
- 3240 in³
- Aspiration
- TA
- Bore
- 6.7 in
- Stroke
- 7.7 in
Generator Set Dimensions
- Length
- 294 in
- Width
- 67 in
- Height
- 86 in
- Dry Weight - Genset
- 43651.1 lb
Standard Equipment
-
- Air Inlet
-
- Turbocharger with a water-cooled bearing case for all cylinder
- One-element single-stage air cleaner with enclosure and sevice indicator
-
- Control Panels
-
- TEM (Total Electronic Management)
-
- Cooling
-
- Jacket water and SCAC thermostats
- flange connections for JW inlet and outlet
- Electrical jacket water and aftercooler coolant pump
-
- Exhaust
-
- Closed crankcase ventilation system
- PEARL/Low resistence exhaust system
- Exhaust waste gate for the CG170-20
-
- Fuel System
-
- Pre-chamber spark plugs
- Electronic fuel metering valve
- Independently controlled cylinder monitoring and ignition system
-
- Generator
-
- Winding temperature detectors
- 3-phase sensing and KVAR/PF control
- Reactive droop
- closed-coupled generator result in no torque transmission to the base frame
- grid code generator
- Anti-condensation space heater
- Busbar connections
-
- Starting/charging
-
- 24V starting motors
- Battery disconnect switch
-
- General
-
- Crankshaft vibration damper and guard
Attachments
-
- Cooling
-
- CHP skid
-
- Grid Code Compliance
-
- 50Hz: Germany, Belgium, Great Britain, Italy, Poland, and Netherlands
